INVT Goodrive350 Series Operation Manual page 336

Goodrive350 IP55 High-ingress Protection Series VFD
Symbol Description
Expansion card
⑤
Symbol Description
①
Product category EC expansion card
②
③
Distinguishing
④
⑤
requirement
code 02: Wi-Fi communication card
03: PROFIBUS communication card
04: Ethernet communication card
05: CAN multi-protocol communication card
06: DeviceNet communication card
07: BACnet communication card
08: EtherCAT communication card
09: PROFINET communication card
10: 485 communication card
15: Modbus TCP communication card
Empty: Version A
B: Version B
version
C: Version C
EC-IO 5 01-00
① ② ③ ④ ⑤
IC: IoT card
IO: IO expansion card
Board card PC: Programmable card
category PG: PG card
PS: Power supply card
TX: communication extension card
Indicates the generation of a technical version by using odd
Technology
numbers, for example, 1, 3, 5, and 7 indicate the 1st, 2nd, 3rd
version
and 4th generations of the technical version.
01: Multiple-function I/O expansion card (four digital inputs, one
digital output, one analog input, one analog output, and two
relay outputs)
02: Digital I/O card
code
03: Analog I/O card
04: Reserved 1
05: Reserved 2
Special
Naming example
Naming example
-318-
Expansion card
