Setting Function
28 Reset the counter
Switch between speed
29
control and torque control
30 Disable ACC/DEC
31 Trigger the counter
Clear the frequency
33 increase/decrease setting
temporarily
34 DC braking
Switch between motor 1
35
and motor 2
Switch the running
command channel to
36
Switch the running
command channel to
37
Switch the running
command channel to
38
communication
Pre-exciting command
39
Clear power consumption
40
Keep power consumption
41
Switch the setting source
42 of braking torque upper
limit to keypad
Position reference point
43
Disable spindle orientation Spindle positioning is disabled.
44
Spindle zeroing / Local
45
positioning zeroing
The counter is cleared.
The VFD switches from torque control mode to speed
control mode, or vice versa.
Used to ensure the VFD is not impacted by external signals
(except for stop command), and maintains the present
output frequency.
Used to enable the counter to count pulses.
When the terminal is closed, the frequency value set by the
UP/DOWN key can be cleared and restored to the
frequency given by frequency command channel; when the
terminal is opened, it is changed to the frequency value after
frequency increase/decrease setting.
The VFD starts DC brake immediately after the command
becomes valid.
When the function is enabled, you can realize switchover
control of two motors.
When the function is enabled, the running command
channel is switched to keypad. When the function is
disabled, the running command channel is restored to the
keypad
previous setting.
When the function is enabled, the running command
channel is switched to terminal. When the function is
disabled, the running command channel is restored to the
terminal
previous setting.
When the function is enabled, the running command
channel is switched to communication. When the function is
disabled, the running command channel is restored to the
previous setting.
When the function is enabled, motor pre-exciting is started
until the function becomes invalid.
After this command becomes valid, the power consumption
quantity quantity of the VFD will be zeroed out.
When the function is enabled, the present operation of the
quantity VFD does not impact the power consumption quantity.
The torque upper limit is set through the keypad when the
command is valid.
Only valid for S1, S2, S3
input
Trigger the spindle positioning function
Description
