INVT Goodrive350 Series Operation Manual page 324

Goodrive350 IP55 High-ingress Protection Series VFD
Function
description
VFD fault code
VFD
identification
code
Running
frequency
Set frequency
Bus voltage
Output voltage
Output current
Rotational speed
Output power
Output torque
Closed-loop
setting
Closed-loop
feedback
Input IO state
Output IO state
Analog input 1
Analog input 2
Analog input 3
Analog input 4
Read input of
HDIA high-speed
pulse
Address
Bit8=0: Speed control =1: Torque control
Bit9=0: Non position control
=1: Position control
Bit11–Bit10=0: Vector 0
2102H See the description of fault types.
2103H GD350-----0x01A0
3000H 0–Fmax (Unit: 0.01Hz)
3001H 0–Fmax (Unit: 0.01Hz)
3002H 0.0–2000.0V (Unit: 0.1V)
3003H 0–1200V (Unit: 1V)
3004H 0.0–3000.0A (Unit: 0.1A)
3005H 0–65535 (Unit: 1RPM)
3006H -300.0–300.0% (Unit: 0.1%)
3007H -250.0–250.0% (Unit: 0.1%)
3008H -100.0–100.0% (Unit: 0.1%)
3009H -100.0–100.0% (Unit: 0.1%)
0x00–0x3F
300AH Corresponding
HDIA/S4/S3/S2/S1
0x00–0x0F
300BH Corresponding
RO2/RO1/HDO/Y1
300CH 0.00–10.00V (Unit: 0.01V)
300DH 0.00–10.00V (Unit: 0.01V)
300EH -10.00–10.00V (Unit: 0.01V)
300FH
3010H 0.00–50.00kHz (Unit: 0.01Hz)
Data description
=1: Vector 1
=2: Closed-loop vector
= 3: Space voltage vector
to the local
to
-306-
Communication protocol
Compatible
with
CHF100A
and CHV100
communicati
HDIB/
on
addresses
local
R/W
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
