Goodrive350 IP55 High-ingress Protection Series VFD
Related parameter list:
Function
code
P05.00 HDI input type
P05.01 Function of S1
P05.02 Function of S2
P05.03 Function of S3
P05.04 Function of S4
P05.05 Function of HDIA
P05.06 Function of HDIB
Name
0x00–0x11
Ones place: HDIA input type
0: HDIA is high-speed pulse input
1: HDIA is digital input
Tens place: HDIB input type
0: HDIB is high-speed pulse input
1: HDIB is digital input
0: No function
1: Run forward
2: Run reversely
3: Three-wire running control
4: Jog forward
5: Jog reversely
6: Coast to stop
7: Reset faults
8: Pause running
9: External fault input
10: Increase frequency setting (UP)
11: Decrease frequency setting (DOWN)
12: Clear the frequency increase/decrease
setting
13: Switch between A setting and B setting
14: Switch between combination setting and A
setting
15: Switch between combination setting and B
setting
16: Multi-step speed terminal 1
17: Multi-step speed terminal 2
18: Multi-step speed terminal 3
19: Multi-step speed terminal 4
20: Pause multi-step speed running
21: ACC/DEC time selection 1
22: ACC/DEC time selection 2
23: Simple PLC stop reset
24: Pause simple PLC
25: Pause PID control
26: Pause wobbling frequency
27: Reset wobbling frequency
Description
-88-
Basic operation guidelines
Default
0x00
1
4
7
0
0
0
