Goodrive350 IP55 High-ingress Protection Series VFD
Function
Name
code
card gateway 2
Industrial Ethernet
P16.68 communication
card gateway 3
Industrial Ethernet
P16.69 communication
card gateway 4
Group P17—Status viewing
Function
Name
code
P17.00 Set frequency
P17.01 Output frequency
Ramp reference
P17.02
frequency
P17.03 Output voltage
P17.04 Output current
Motor rotation
P17.05
speed
P17.06 Torque current
P17.07 Exciting current
P17.08 Motor power
Description
0–255
0–255
Description
Displays the present set frequency of the VFD.
Range: 0.00Hz–P00.03
Displays the present output frequency of the
VFD.
Range: 0.00Hz–P00.03
Displays the present ramp reference frequency
of the VFD.
Range: 0.00Hz–P00.03
Displays the present output voltage of the VFD.
Range: 0–1200V
Displays the valid value of present output
current of the VFD.
Range: 0.0–5000.0A
Displays the present motor rotation speed.
Range: 0–65535rpm
Displays the present torque current of the VFD.
Range: -3000.0–3000.0A
Displays the present exciting current of the
VFD.
Range: -3000.0–3000.0A
Displays the present motor power. 100%
corresponds to the rated motor power. The
positive value is the motoring state while the
negative value is the generating state.
Range: -300.0–300.0% (relative to the rated
motor power)
-214-
Function parameter list
Default Modify
◎
0
◎
1
Default Modify
●
0.00Hz
●
0.00Hz
●
0.00Hz
●
0V
●
0.0A
●
0rpm
●
0.0A
●
0.0A
●
0.0%
