INVT Goodrive350 Series Operation Manual page 391

Goodrive350 IP55 High-ingress Protection Series VFD
C.3 VFD dimension
C.3.1 Wall-mounting dimensions
Figure C-2 Wall-mounting diagram for the 004G/5R5P–037G/045P models
VFD model
GD350-004G/5R5P-45-AS
GD350-5R5G/7R5P-45-AS
GD350-004G/5R5P-45-NS
GD350-5R5G/7R5P-45-NS
GD350-7R5G/011P-45-AS
GD350-011G/015P-45-AS
GD350-015G/018P-45-AS
GD350-7R5G/011P-45-NS
GD350-011G/015P-45-NS
GD350-015G/018P-45-NS
GD350-018G/022P-45-AS
GD350-022G/030P-45-AS
GD350-018G/022P-45-NS
GD350-022G/030P-45-NS
GD350-030G/037P-45-AS
GD350-037G/045P-45-AS
GD350-030G/037P-45-NS
GD350-037G/045P-45-NS
W1
W2
Table C-1 Wall-mounting dimensions
W1 W2 H1 H2
196 164 428.5 403
223 187 503.8 475 458.5
274 234 551.5 522
318 263 619 587 566.5
-373-
D1
D2
H3 D1 D2
diameter
262.8
389 227
-
289.4
250.7
-
281.8
504 246
-
290
242.9
-
Dimension drawings
Net
Hole Fixing
weight
screw
(kg)
9
Ø6 M5
8.5
13
Ø7 M6
12.5
21
Ø7 M6
20
27
Ø9 M8
26.5
Gross
weight
(kg)
11
10.5
16
15
24.5
23
31.5
30
