Function
Name
code
HDIA input
P17.21
frequency
HDIB input
P17.22
frequency
PID reference
P17.23
value
P17.24 PID feedback value
P17.25 Motor power factor
P17.26 Duration of this run
Present step of
P17.27
simple PLC
Motor ASR
P17.28
controller output
Open-loop SM pole
P17.29
angle
Phase
P17.30 compensation of
SM
High-frequency
P17.31 superposition
current of SM
P17.32 Motor flux linkage 0.0%–200.0%
Exciting current
P17.33
reference
Torque current
P17.34
reference
AC incoming
P17.35
current
Description
Range: -10.00V–10.00V
Display HDIA input frequency.
Range: 0.000–50.000kHz
Display HDIB input frequency.
Range: 0.000–50.000kHz
Displays the PID reference value.
Range: -100.0–100.0%
Displays the PID feedback value.
Range: -100.0–100.0%
Displays the power factor of the current motor.
Range: -1.00–1.00
Displays the duration of this run of the VFD.
Range: 0–65535min
Used to display the present step of the simple
PLC function.
Displays the ASR controller output value under
the vector control mode, relative to the
percentage of rated motor torque.
Range: -300.0%–300.0% (of the motor rated
current)
Displays the initial identification angle of SM.
Range: 0.0–360.0
Displays the phase compensation of SM.
Range: -180.0–180.0
0.0%–200.0% (of the motor rated current)
Displays the exciting current reference value
under the vector control mode.
Range: -3000.0–3000.0A
Displays the torque current reference value
under the vector control mode.
Range: -3000.0–3000.0A
Displays the valid value of incoming current on
AC side.
-216-
Function parameter list
Default Modify
0.000
●
kHz
●
0.000 kHz
●
0.0%
●
0.0%
●
0.00
●
0min
●
0
●
0.0%
●
0.0
●
0.0
●
0.0
●
0.0%
●
0.0A
●
0.0A
●
0.0A
