Goodrive350 IP55 High-ingress Protection Series VFD
Function
Name
code
SM angle
P24.23 compensation
coefficient
Number of pole
P24.24 pairs in initial pole
angle autotuning
Group P25––I/O card input functions
Function
Name
code
P25.00 HDI3 input type
P25.01 Function of S5
P25.02 Function of S6
P25.03 Function of S7
P25.04 Function of S8
P25.05 Function of S9
P25.06 Function of S10
P25.07 Function of HDI3
Expansion card
P25.08 input terminal
polarity
Expansion card
P25.09 virtual terminal
setting
HDI3 switch-on
P25.10
delay
HDI3 switch-off
P25.11
delay
P25.12 S5 switch-on delay
P25.13 S5 switch-off delay
P25.14 S6 switch-on delay
Description
-200.0–200.0%
1–128
Description
0: HDI3 is high-speed pulse input
1: HDI3 is digital input
Same as the description for P05
0x00–0x7F
0x00–0x7F (0: Disable. 1: Enable)
Bit0: S5 virtual terminal
Bit1: S6 virtual terminal
Bit2: S7 virtual terminal
Bit3: S8 virtual terminal
Bit4: S9 virtual terminal
Bit5: S10 virtual terminal
Bit6: HDI3 virtual terminal
The function codes specify the delay time
corresponding to the electrical level changes
when the programmable input terminals switch
on or switch off.
-243-
Function parameter list
Default Modify
○
100.0%
◎
2
Default Modify
◎
0
◎
0
◎
0
◎
0
◎
0
◎
0
◎
0
◎
0
○
0x00
◎
0x00
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
