INVT Goodrive350 Series Operation Manual page 150

Goodrive350 IP55 High-ingress Protection Series VFD
Function
Name
code
of braking for stop During the deceleration to stop, the VFD starts
Demagnetization
P01.10
time
DC braking current
P01.11
for stop
DC braking time for
P01.12
stop
FWD/REV run
P01.13
deadzone time
Description
DC braking for stop when running frequency
reaches the starting frequency determined by
P01.09.
Wait time before DC braking: The VFD blocks
the output before starting DC braking. After this
wait time, DC braking is started so as to prevent
overcurrent caused by DC braking at high
speed.
DC braking current for stop: It indicates the
applied DC braking energy. Stronger current
indicates greater DC braking effect.
DC braking time for stop: It indicates the hold
time of DC braking. If the time is 0, DC braking
is invalid, and the VFD decelerates to stop
within the specified time.
ACC
P01.04
P01.23 P01.30
Setting range of P01.09:
output frequency)
Setting range of P01.10: 0.00–30.00s
Setting range of P01.11: 0.0–100.0% (of the
rated VFD output current)
Setting range of P01.12: 0.0–50.0s
This function code indicates the transition time
specified in P01.14 during FWD/REV rotation
switching. See the figure.
Output frequency f
Forward
Starting
frequency
Setting range: 0.0–3600.0s
-132-
P01.09
P01.31
Constant speed
DEC
P01.12
P01.10
In running
0.00Hz–P00.03
Switch over after
starting frequency
Switch over after
zero frequency
Deadzone
Reverse
time
Function parameter list
Default Modify
0.00s
0.0%
0.00s
Time t
(Max.
0.0s
Time t
○
○
○
○
