Goodrive350 IP55 High-ingress Protection Series VFD Basic operation guidelines
Function
Name Description Default
code
14: Overload pre-alarm
15: Underload pre-alarm
16: Simple PLC stage completed
17: Simple PLC cycle completed
18: Set counting value reached
19: Designated counting value reached
20: External fault is valid
21: Reserved
22: Running time reached
23: Modbus/ Modbus TCP communication
virtual terminal output
24: PROFIBUS/CANopen/DeviceNet
communication virtual terminal output
25: Ethernet communication virtual terminal
output
26: DC bus voltage established
27: Z pulse output
28: Superposing pulses
29: STO action
30: Positioning completed
31: Spindle zeroing completed
32: Spindle scale division completed
33: Speed limit reached in torque control
34: EtherCAT/PROFINET/EtherNet IP
communication virtual terminal output
35: Reserved
36: Speed/position control switchover
completed
37: Any frequency reached
38–40: Reserved
41: Y1 from the programmable card
42: Y2 from the programmable card
43: HDO from the programmable card
44: RO1 from the programmable card
45: RO2 from the programmable card
46: RO3 from the programmable card
47: RO4 from the programmable card
48: EC PT100 detected OH pre-alarm
-95-
