Goodrive350 IP55 High-ingress Protection Series VFD
Function
Name
code
Initial roll diameter
P90.18
Initial roll diameter
P90.19
Linear speed roll
diameter
P90.20
calculation filter
time
Linear speed roll
diameter
P90.21
calculation
restriction
P90.22 Material thickness 0.001–65.535mm
Number of coils per
P90.23
layer
Revolution counting
P90.24
function selection
Number of pulses
P90.25
per revolution
Roll diameter set
P90.26
value
Roll diameter reset
P90.27
setting
P90.15–P90.16
2
P90.15–P90.16
3
0.000–60.000s
0x00–0x11
Ones place:
0:No
1: Restrict changes in reverse direction
Tens place:
0:No
1: Automatic restriction according to running
frequency and material thickness
1–10000
0: Digital terminal input
1: PG card input (applicable to thickness
calculation method)
2: Running frequency (no input automatic
revolution counting)
1–60
0.0–100.0%
0x0000–0x1111
Ones place: At stop
0: Remain current roll diameter
1: Restore to initial roll diameter
Tens place: Power off at running
0: Remain current roll diameter
1: Restore to initial roll diameter
Hundreds place: Reach the roll diameter set
value
Description
-257-
Function parameter list
Default Modify
○
100.0 mm
○
100.0 mm
○
2.000s
○
0x00
0.010
○
mm
◎
1
◎
0
◎
1
○
80.0%
○
0x1000
