INVT Goodrive350 Series Operation Manual page 75

Goodrive350 IP55 High-ingress Protection Series VFD
Function
code
Proportional coefficient in
P04.42
IF mode for AM 1
Integral coefficient in IF
P04.43
mode for AM 1
Starting frequency point
P04.44 for switching off IF mode
Enabling IF mode for AM
P04.45
Current setting in IF mode
P04.46
Proportional coefficient in
P04.47
IF mode for AM 2
Integral coefficient in IF
P04.48
mode for AM 2
Starting frequency point
P04.49 for switching off IF mode
End frequency point for
P04.50 switching off IF mode for
End frequency point for
P04.51 switching off IF mode for
Name
Setting range: 0.0–200.0%
When IF control is adopted for AM 1, the
function code is used to set the proportional
coefficient of the output current closed-loop
control.
Setting range: 0–5000
When IF control is adopted for AM 1, the
function code is used to set the integral
coefficient of the output current closed-loop
control.
Setting range: 0–5000
0.00–P04.50
for AM 1
0: Disable
2 1: Enable
When IF control is adopted for AM 2, the
function code is used to set the output current.
The value is a percentage in relative to the
for AM 2
rated current of the motor.
Setting range: 0.0–200.0%
When IF control is adopted for AM 2, the
function code is used to set the proportional
coefficient of output current closed-loop control.
Setting range: 0–5000
When IF control is adopted for AM 2, the
function code is used to set the integral
coefficient of output current closed-loop control.
Setting range: 0–5000
0.00–P04.51
for AM 2
P04.44–P00.03
AM 1
P04.49–P00.03
AM 2
Description
-57-
Basic operation guidelines
Default
350
150
10.00Hz
0
120.0%
350
150
10.00Hz
25.00Hz
25.00Hz
