Goodrive350 IP55 High-ingress Protection Series VFD
Function
Name
code
Enabling dynamic
P08.37
braking
Dynamic braking
P08.38
threshold voltage
Fan operating
P08.39
mode
P08.40 PWM selection
Overmodulation
P08.41
selection
Description
0: Disable
1: Enable
The function code is used to set the starting bus
voltage of dynamic braking. Adjust this value
properly to achieve effective braking for the
load. The default value varies depending on the
voltage class.
Setting range: 200.0–2000.0V
0: Normal mode
1: The fan keeps running after power-on
2: Run mode 2
0x0000–0x1121
Ones place: PWM mode selection
0: PWM mode 1, 3PH modulation and 2PH
modulation
1: PWM mode 2, 3PH modulation
Tens place: PWM low-speed carrier frequency
limit
0: Low-speed carrier frequency limit mode 1
1: Low-speed carrier frequency limit mode 2
2: No limit on low-speed carrier frequency
Hundreds place:
method
0: Compensation method 1
1: Compensation method 2
Thousands place: PWM loading mode selection
0: Interruptive loading
1: Normal loading
0x0000–0x1111
Ones place:
0: Disable
1: Enable
Tens place:
0: Mild overmodulation
1: Deepened overmodulation
Hundreds place: Carrier frequency limit
0:Yes
1:No
-177-
Deadzone compensation
Function parameter list
Default Modify
○
1
For 220V:
380.0V
○
For 380V:
700.0V
○
0
◎
0x1101
◎
0x1001
