Goodrive350 IP55 High-ingress Protection Series VFD
Assume that the following response is returned:
01
VFD
address
The data content returned by the VFD is 0003H, which indicates that the VFD is in the stopped
state.
Example 2: View information about the VFD whose address is 03H, including "Type of present
fault" (P07.27) to "Type of 5th-last fault" (P07.32) of which the parameter addresses are
071BH to 0720H (contiguous 6 parameter addresses starting from 071BH).
The command transmitted to the VFD is as follows:
03
VFD
address
Assume that the following response is returned:
03 03 0C 00 23 00 23 00 23 00 23
VFD Read Number of
address command
bytes
According to the returned data, all the fault types are 0023H, that is, 35 in the decimal form,
which means the STo fault.
9.4.7.2 Example of writing command 06H
Example 1: Set the VFD whose address is 03H to run forward. According to the table of
address description of other function codes in section 9.4.4.2 Addresses of other Modbus
functions, the parameter address of "communication-based control command" is 2000H and
forward running is 0001H. See the following figure.
Function
description
Communication
-based control
command
03 02
Number
Read
of bytes
command
03 07 1B
Read
Start
command
address
Most recent
Last fault
fault type
type
Address
0001H: Run forward
0002H: Run reversely
0003H: Jog forward
0004H: Jog reversely
2000H
0005H: Stop
0006H: Coast to stop
0007H: Fault reset
0008H: Jogging stop
00 03
Data content
00 06
6 parameters in total
2nd-last fault 3rd-last fault
type type
Data description
-311-
Communication protocol
F8 45
CRC
B5 59
CRC
00 23 00 23
4th-last fault 5th-last fault
type type
R/W
R/W
5F D2
CRC
