Goodrive350 IP55 High-ingress Protection Series VFD
Function
description
VFD status word
1
VFD status word
2
Address
Special control command word
Bit1–2: = 00: Motor 1
Bit2: =1: Enable speed/torque control switchover
=0: Disable speed/torque control switchover
Bit3: =1: Clear electricity consumption data
2009H
=0: Keep electricity consumption data
Bit4: =1: Enable pre-excitation
=0: Disable pre-excitation
Bit5: =1: Enable DC braking
=0: Disable DC braking
Virtual input terminal command. Range: 0x000–0x3FF
200AH (corresponding
HDIA/S4/S3/S2/S1 in sequence)
Virtual output terminal command (range: 0x00–0x0F)
200BH
(corresponding to local RO2/RO1/HDO/Y1)
Voltage setting (used when V/F separation is
implemented)
200CH
(0–1000, in which 1000 corresponds to 100.0% of the
motor rated voltage)
AO setting
200DH
corresponding to 100.0%)
AO setting
200EH
corresponding to 100.0%)
0001H: Forward running
0002H: Reverse running
0003H: Stopped
2100H
0004H: Faulty
0005H: POFF state
0006H: Pre-exciting
Bit0: =0: Not ready to run =1: Ready to run
Bit2–2: = 00: Motor 1
Bit3: =0: AM =1: SM
Bit4: = 0: No pre-alarm upon overload
2101H Overload pre-alarm
Bit6–bit5=00: Keypad-based control
=01: Terminal-based control
=10: Communication-based control
Bit7: Reserved
Data description
=01: Motor 0
to S8/S7/S6/S5/HDIB/
1 (-1000–+1000,
2 (-1000–+1000,
=01: Motor 1
-305-
Communication protocol
in which 1000
in which 1000
=1:
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R
R
