Goodrive350 IP55 High-ingress Protection Series VFD
Signal
Z1+
Z1-
A2+
A2-
B2+
B2-
Z2+
Z2-
AO+
AO-
BO+
BO-
ZO+
ZO-
U+
U-
V+
V-
W+
W-
Description
Pulse reference
Frequency-divided
output
UVW encoder
interface

Differential input of 5V

Response frequency: 200 kHz

Differential output of 5V

Supporting frequency division of 1–255, which can
be set through P20.16 or P24.16

Absolute position (UVW information) of the hybrid
encoder, differential input of 5V

Response frequency: 40kHz
-350-
Expansion card
Description
