INVT Goodrive350 Series Operation Manual page 268

Goodrive350 IP55 High-ingress Protection Series VFD
Function
Name
code
P27.16 C_MoP5
P27.17 C_MoP6
P27.18 C_MoP7
P27.19 C_MoP8
P27.20 C_MoP9
P27.21 C_MoP10
Digital input
P27.22 terminal state of
programmable card
Digital output
P27.23 terminal state of
programmable card
AI1 of the
P27.24
programmable card
AO1 of the
P27.25
programmable card
Length of data sent
by programmable
P27.26 card and PZD
communication
object
Description
The function code is used for the VFD to
monitor/view the MoP4 value of the PLC.
0–65535
The function code is used for the VFD to
monitor/view the MoP5 value of the PLC.
0–65535
The function code is used for the VFD to
monitor/view the MoP6 value of the PLC.
0–65535
The function code is used for the VFD to
monitor/view the MoP7 value of the PLC.
0–65535
The function code is used for the VFD to
monitor/view the MoP8 value of the PLC.
0–65535
The function code is used for the VFD to
monitor/view the MoP9 value of the PLC.
0–65535
The function code is used for the VFD to
monitor/view the MoP10 value of the PLC.
0x00–0x3F
The function code is used to display the input
terminal status on the programmable card.
Bit5–bit0 indicate PS6–PS1.
0x0–0x3
The function code is used to display the output
terminal status on the programmable card. Bit0
indicates PRO1, and bit1 indicates PRO2.
0–10.00V/0.00–20.00mA
The function code is used to display the AI1
value from the programmable card.
0–10.00V/0.00–20.00mA
The function code is used to display the AO1
value from the programmable card.
0x00–0x28
Ones place: Quantity of data sent from the
programmable card and VFD (that is, quantity
of data sent from the programmable card +
from VFD sending table 1 + from VFD sending
table 2)
-250-
Function parameter list
Default Modify
●
0
●
0
●
0
●
0
●
0
●
0
●
0x00
●
0x0
●
0
●
0
○
0x03
