INVT Goodrive350 Series Operation Manual page 254

Goodrive350 IP55 High-ingress Protection Series VFD
Function
Name
code
Spindle zeroing
P22.04
position 1
Spindle zeroing
P22.05
position 2
Spindle zeroing
P22.06
position 3
Spindle
P22.07 scale-division angle
Spindle
P22.08 scale-division angle
Spindle
P22.09 scale-division angle
Spindle
P22.10 scale-division angle
Spindle
P22.11 scale-division angle
Spindle
P22.12 scale-division angle
Spindle
P22.13 scale-division angle
P22.14 Spindle drive ratio
Spindle zero-point
P22.15 communication
setting
P22.16 Reserved
Setting range: 0–65535
Setting range: 0–65535
Setting range: 0–65535
Setting range: 0–65535
You can select seven spindle scale-division
angles by terminals (functions 48, 49, and 50).
1 Setting range: 0.00–359.99
Setting range: 0.00–359.99
2
Setting range: 0.00–359.99
3
Setting range: 0.00–359.99
4
Setting range: 0.00–359.99
5
Setting range: 0.00–359.99
6
Setting range: 0.00–359.99
7
Used to set the reduction ratio of the spindle
and the mounting shaft of the encoder.
Setting range: 0.000–30.000
P22.15 is used to set spindle zero-point offset.
If the selected spindle zero point is P22.03, the
final spindle zero point will be the sum of
P22.03 and P22.15.
Setting range: 0–39999
-
Description
-236-
Function parameter list
Default Modify
○
0
○
0
○
0
○
15.00
○
30.00
○
45.00
○
60.00
○
90.00
○
120.00
○
180.00
○
1.000
○
0
- -
