INVT Goodrive350 Series Operation Manual page 181

Goodrive350 IP55 High-ingress Protection Series VFD
Function
Name
code
HDO switch-on
P06.08
delay
HDO switch-off
P06.09
delay
RO1 switch-on
P06.10
delay
RO1 switch-off
P06.11
delay
RO2 switch-on
P06.12
delay
RO2 switch-off
P06.13
delay
AO1 output
P06.14
selection
P06.15 Reserved
HDO high-speed
P06.16
pulse output
Description
programmable output terminals switch on or
switch off.
Y electric level
Invalid
Y valid
Switch on
delay
Setting range: 0.000–50.000s
Note: P06.08 and P06.09
P06.00=1.
0: Running frequency (0–Max. output
frequency)
1: Set frequency (0–Max. output frequency)
2: Ramp reference frequency (0–Max. output
frequency)
3: Rotational speed (0–Speed corresponding to
max. output frequency)
4: Output (0–Twice the VFD rated current)
5: Output current (0–Twice the motor rated
current)
6: Output (0–1.5 times the VFD rated voltage)
7: Output power (0–Twice the motor rated
power)
8: Set torque (0–Twice the motor rated torque)
9: Output torque (Absolute value, 0–±Twice the
motor rated torque)
10: AI1 input (0–10V/0–20mA)
11: AI2 input (0–10V)
12: AI3 input (0–10V/0–20mA)
13: HDIA input (0.00–50.00kHz)
14: Value 1 set through Modbus/Modbus TCP
communication (0–1000)
15: Value 2 set through Modbus/Modbus TCP
communication (0–1000)
16: Value 1 set through
PROFIBUS/CANopen/DeviceNet (0–1000)
-163-
Function parameter list
invalid
Valid
Switch off
delay
are valid only when
Default Modify
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0
○
0
