INVT Goodrive350 Series Operation Manual page 252

Goodrive350 IP55 High-ingress Protection Series VFD
Function
Name
code
Speed feedforward
filtering time
P21.29 constant (pulse
train-based speed
mode)
Numerator of the
P21.30
2nd command ratio
Speed measuring
P21.31 method of pulse
reference
Pulse reference
P21.32
feedforward source
Setting of encoder
P21.33 count value
clearing
Group P22––Spindle positioning
Function
Name
code
Spindle positioning
P22.00
mode selection
Description
electronic gear are still valid for superposed
pulses.
4. Output terminal function 28 (during pulse
superposition)
During the pulse superposition, the output
terminal is valid. After the pulse superposition is
completed, the output terminal is invalid.
Filter time constant detected by the pulse train
when the speed reference source is set to the
pulse train (P00.06=12 or P00.07=12).
Setting range: 0–3200.0ms
1–65535
0–2
0: By main control board
1: By PG card
2: Hybrid method
0x0–0x1
0–65535
Description
0x0000–0xFFFF
Bit0: Enable/disable spindle positioning
0: Disable
1: Enable
Bit1: Spindle positioning
selection
0: Z pulse input
1: S2/S3/S4 terminal input
Bit2: Search for reference point
0: Search the reference point only once
1: Search the reference point every time
-234-
Function parameter list
Default Modify
10.0ms
Default Modify
reference point
0x0000
○
○
1000
○
0
◎
0x0
◎
0
○
