INVT Goodrive350 Series Operation Manual page 350

Goodrive350 IP55 High-ingress Protection Series VFD
A.4.2 IO expansion card 2 (EC-IO502-00)
The terminals are arranged as follows:
PT1+
S5 S6
+24V PW
Indicator definition:
Indicator Definition
Status
LED1
indicator
Power
LED4
indicator
EC-IO502-00 can be used in scenarios where the I/O interfaces of a VFD cannot meet the
application requirements. It can provide four digital inputs, one PT100 temperature measuring
input (PT1+), one PT1000 temperature measuring input (PT2+), and two relay outputs. It is
user-friendly, providing relay outputs and digital inputs through European-type screw terminals
and temperature measuring inputs through spring terminals.
EC-IO502-00 terminal function description
Terminal
Category
symbol
Power
PW
supply
S7 S8
COM COM
On: The expansion card is establishing a connection with the control
board.
Blinking periodically: The expansion card is properly connected to the
control board (the period is 1s, on for 0.5s, and off for the other 0.5s).
Off: The communication card is disconnected from the control board.
This indicator is on after the IO extension card is powered on by the
control board.
Terminal name
External power
PT-
Function
External power input terminal for digital input
circuits
Voltage range:
24(-10%)–48VAC(+10%) voltage input
-332-
Expansion card
PT2+
RO4A RO4C
RO3A
Description
24(-20%)–48VDC(+10%),
RO3C
