Goodrive350 IP55 High-ingress Protection Series VFD
Function
Name
code
Output terminal
P06.05
polarity selection
P06.06 Y1 switch-on delay Used to specify the delay time corresponding to
P06.07 Y1 switch-off delay
Description
28: Superposing pulses
29: STO action
30: Positioning completed
31: Spindle zeroing completed
32: Spindle scale division completed
33: Speed limit reached in torque control
34: EtherCAT/PROFINET/EtherNet IP
communication virtual terminal output
35: Reserved
36: Speed/position control switchover
completed
37: Any frequency reached
38–40: Reserved
41: Y1 from the programmable card
42: Y2 from the programmable card
43: HDO from the programmable card
44: RO1 from the programmable card
45: RO2 from the programmable card
46: RO3 from the programmable card 47: RO4
from the programmable card
48: EC PT100 detected OH pre-alarm
49: EC PT1000 detected OH pre-alarm
50: AIAO detected OT pre-alarm
51: Stopped or running in zero speed
52: Tension control disconnection
53: Specified roll diameter reached
54: Max. roll diameter reached
55: Min. roll diameter reached
56: Fire mode enabled
57–63: Reserved
Used to set the output terminal polarity.
When a bit is 0, the output terminal is positive.
When a bit is 1, the output terminal is negative.
Bit3 Bit2
RO2 RO1
Setting range: 0x00–0x0F
the electrical level
-162-
Bit1 Bit0
HDO Y
changes when the
Function parameter list
Default Modify
○
0x00
○
0.000s
○
0.000s
