Goodrive350 IP55 High-ingress Protection Series VFD
VFD model
GD350-055G/075P-45-AS-B
GD350-055G/075P-45-NS-B
GD350-075G/090P-45-AS
GD350-075G/090P-45-NS
GD350-075G/090P-45-AS-B
GD350-075G/090P-45-NS-B
GD350-090G/110P-45-AS
GD350-090G/110P-45-NS
GD350-090G/110P-45-AS-B
GD350-090G/110P-45-NS-B
GD350-110G-45-AS
GD350-110G-45-NS
GD350-110G-45-AS-B
GD350-110G-45-NS-B
Note: The accessory specifications described in the preceding table are ideal values. You can
select accessories based on the actual market conditions, but try not to use those with lower
values.
D.6 Harmonic filter
To enhance grid protection, reduce harmonic interference from the VFD to the grid, and
improve input power factor, consider configuring external DC reactors, input reactors, or
passive harmonic filters based on your specific application needs.
If you want to use long cables between the VFD and the motor, select external output reactors,
dv/dt attenuation filters, or sine-wave filters based on the motor cable length. This helps
mitigate excessive dv/dt, reducing voltage stress on the motor windings as well as protecting
them, and extending the motor's lifespan. Refer to the table below for recommended output
filter selections according to motor cable length.
Output filter category
Output reactor (1%)
dv/dt decrement filters
Sine-wave filter
VFD power
4kW
5.5kW
Breaker rated
current (A)
200
250
315
Table D-5 Output filter selection for motor cable lengths
Shielded cable length
Table D-6 Reactor model selection
GDL-ACL0014-4CU
GDL-ACL0020-4CU
Fast-acting fuse rated
current (A)
30m–100m
100m–230m
230m–500m
Input reactors
-387-
Optional peripheral accessories
Contactor rated
current AC-3 (A)
250
315
355
Non-shielded cable length
50m–150m
150m–450m
450m–1000m
Output reactors
GDL-OCL0010-4CU
GDL-OCL0014-4CU
145
185
210
