INVT Goodrive350 Series Operation Manual page 322

Goodrive350 IP55 High-ingress Protection Series VFD

The service life of the Electrically Erasable Programmable Read-Only Memory
(EEPROM) may be reduced if it is frequently used for storage. Some function codes do
not need to be stored during communication. The application requirements can be met
by modifying the value of the on-chip RAM, that is, modifying the MSB of the
corresponding function code address from 0 to 1. For example, if P00.07 is not to be
stored in the EEPROM, you need only to modify the value of the RAM, that is, set the
address to 8007H. The address can be used only for writing data to the on-chip RAM,
and it is invalid when used for reading data.
9.4.4.2 Addresses of other Modbus functions
In addition to modifying the parameters of the VFD, the master can also control the VFD, such
as starting and stopping the VFD, and monitoring the running status of the VFD. The following
table lists other function parameters.
Function
description
Communication-
based control
command
Communication-
based setting
address
Address
0001H: Run forward
0002H: Run reversely
0003H: Jog forward
0004H: Jog reversely
2000H
0005H: Stop
0006H: Coast to stop
0007H: Fault reset
0008H: Jogging stop
Communication-based frequency setting (0–Fmax;
2001H
unit: 0.01 Hz)
PID reference (0–1000, in which 1000 corresponds to
2002H
100.0%)
PID feedback (0–1000, in which 1000 corresponds to
2003H
100.0%)
Torque
2004H
corresponds to 100.0% of the motor rated current)
Upper limit setting of forward running frequency (0–
2005H
Fmax; unit: 0.01 Hz)
Upper limit setting of reverse running frequency (0–
2006H
Fmax; unit: 0.01Hz)
Electromotive torque upper limit (0–3000, in which
2007H 1000 corresponds to 100.0% of the motor rated
current)
Braking torque upper limit (0–3000, in which 1000
2008H
corresponds to 100.0% of the motor rated current)
Data description
setting (-3000–3000,
-304-
Communication protocol
in which 1000
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
