INVT Goodrive350 Series Operation Manual page 173

Goodrive350 IP55 High-ingress Protection Series VFD
Function
Name
code
P05.07 Reserved
Input terminal
P05.08
polarity selection
Digital input filter
P05.09
time
Description
57: Motor overtemperature fault input
58: Enable rigid tapping
59: Switch to V/F control
60: Switch to FVC control
61: Switch PID polarities
62: Reserved
63: Enable servo
64: Limit on forward running
65: Limit on reverse running
66: Clear encoder counting
67: Increase pulses
68: Enable pulse superposition
69: Decrease pulses
70: Electronic gear selection
71: Switch to the master
72: Switch to the slave
73: Roll diameter reset
74: Winding/unwinding switchover
75: Tension control pre-driving
76: Disable roll diameter calculation
77: Clear alarm display
78: Manual braking in tension control
79: Trigger a forcible material feeding interrupt
signal
80: Initial roll diameter selection 1
81: Initial roll diameter selection 2
82: Triggering fire control
83: Tension PID switchover
84–95: Reserved
-
The function code is used to set the polarity of
input terminals.
When a bit is 0, the input terminal is positive.
When a bit is 1, the input terminal is negative.
0x00–0x3F
Used to specify the sampling filter time of the
S1–S4 and HDI
interference cases, increase the value to avoid
-155-
terminals. In strong
Function parameter list
Default Modify
- -
○
0x00
○
0.010s
