INVT Goodrive350 Series Operation Manual page 136

Goodrive350 IP55 High-ingress Protection Series VFD
Function
code
Running frequency at
P07.33
Ramp reference frequency
P07.34
at present fault
Output current at present
P07.35
Output current at present
P07.36
Bus voltage at present
P07.37
Max. temperature at
P07.38
Input terminal status at
P07.39
Output terminal status at
P07.40
Running frequency at last
P07.41
Ramp reference frequency
P07.42
P07.43 Output voltage at last fault 0–1200V
P07.44 Output current at last fault 0.0–6300.0A
P07.45 Bus voltage at last fault
Max. temperature at last
P07.46
Input terminal state at last
P07.47
Output terminal state at
P07.48
Name
present fault
fault
fault
fault
present fault
present fault
present fault
fault
at last fault
fault
fault
last fault
Description
70: EC PT100 detected overheating (OtE1)
71: EC PT1000 detected overheating (OtE2)
72: EtherNet IP communication timeout fault
(E-EIP)
73: No upgrade bootload (E-PAO)
74: AI1 disconnection (E-AI1)
75: AI2 disconnection (E-AI2)
76: AI3 disconnection (E-AI3)
0.00Hz–P00.03
0.00Hz–P00.03
0–1200V
0.0–6300.0A
0.0–2000.0V
-20.0–120.0° C
0x0000–0xFFFF
0x0000–0xFFFF
0.00Hz–P00.03
0.00Hz–P00.03
0.0–2000.0V
-20.0–120.0° C
0x0000–0xFFFF
0x0000–0xFFFF
-118-
Basic operation guidelines
Default
0.00Hz
0.00Hz
0V
0.0A
0.0V
0.0° C
0x0000
0x0000
0.00Hz
0.00Hz
0V
0.0A
0.0V
0.0° C
0x0000
0x0000
