INVT Goodrive350 Series Operation Manual page 183

Goodrive350 IP55 High-ingress Protection Series VFD
Function
Name
code
AO1 output
P06.20 corresponding to
upper limit
AO1 output filter
P06.21
time
P06.22 Reserved
PTC constant
P06.23 output current
setting
PTC resistance
P06.24
alarm threshold
PTC resistance
P06.25 alarm recovery
threshold
Actual PTC
P06.26
resistance
HDO output lower
P06.27
limit
HDO output
P06.28 corresponding to
lower limit
HDO output upper
P06.29
limit
HDO output
P06.30 corresponding to
upper limit
HDO output filter
P06.31
time
P06.32 Reserved
P06.33 Detection value for 0.00Hz–P00.03
Description
In different cases, the corresponding analog
output of 100% of the output value is different.
10V (20mA)
AO
0.0%
Setting range of P06.17:
Setting range of P06.18: 0.00V–10.00V
Setting range of P06.19: P06.17–300.0%
Setting range of P06.20: 0.00V–10.00V
Setting range of P06.21: 0.000s–10.000s
-
0.000–20.000mA
0–60000Ω
0–60000Ω
0–60000Ω
-300.0%–P06.29
0.00–50.00kHz
P06.27–300.0%
0.00–50.00kHz
0.000s–10.000s
-
-165-
100.0%
-300.0%–P06.19
Function parameter list
Default Modify
○
10.00V
○
0.000s
-
-
○
4.000 mA
750Ω
○
150Ω ○
0Ω
●
○
0.00%
○
0.00kHz
○
100.0%
50.00
○
kHz
○
0.000s
- -
○
1.00Hz
