INVT Goodrive350 Series Operation Manual page 354

Goodrive350 IP55 High-ingress Protection Series VFD
Terminal
Category
symbol
input/out PS2—COM
put
PS3—COM
PS4—COM
PS5—COM
PS6—COM
AI1
Analog
input/out
put
AO1
PRO1A
PRO1C
Relay
output
PRO2A
PRO2C
For details about how to use the programmable card, see the Goodrive350 series AutoStation
programmable card manual.
Terminal name
Digital input 2
Digital input 3
Digital input 4
Digital input 5
Digital input 6
Analog input 1
Analog output 1
NO contact of relay
1
Common contact of
relay 1
NO contact of relay
2
Common contact of
relay 2
-336-
Description

12–30V voltage input is acceptable

Bi-direction input terminal

Max. input frequency: 1kHz

Source/sink inputs, and the input type should
be consistent

Input range: For AI1, 0–10V or 0–20mA
Input impedance: 20kΩ for voltage input;

250Ω for current input

Whether voltage or current is used for input is
set through the jumper

Resolution: 5mV when 10V corresponds to
50Hz

Deviation: ± 1%, 25° C, full measuring range

Output range: 0–10V or 0–20mA

Whether voltage or current is used for output
is set through the jumper

Deviation: ± 1%, 25° C, full measuring range

Contact capacity: 2A/AC250V, 1A/DC30V

Cannot be used as high frequency digital
output.
Expansion card
