INVT Goodrive350 Series Operation Manual page 200

Goodrive350 IP55 High-ingress Protection Series VFD
Function
Name
code
PID output
P09.03 characteristics
selection
Proportional gain
P09.04
(Kp)
Description
0: AI1
1: AI2
2: AI3
3: High-speed pulse HDIA
4: Modbus/Modbus TCP communication
5: PROFIBUS/CANopen/DeviceNet
communication
6: Ethernet communication
7: High-speed pulse HDIB
8: EtherCAT/PROFINET/ EtherNet IP
communication
9: Programmable expansion card
10: Reserved
Note: The reference channel and feedback
channel cannot be duplicate. Otherwise,
effective PID control cannot be achieved.
0: PID output is positive. When the feedback
signal is greater than the PID reference value,
the output frequency of the VFD will decrease
to balance the PID. Example: PID control on
strain during unwinding.
1: PID output is negative. When the feedback
signal is greater than the PID reference value,
the output frequency of the VFD will increase to
balance the PID. Example: PID control on
tension during unwinding.
The function is applied to the proportional gain
P of PID input.
P determines the strength of the whole PID
adjuster. The larger the value of P, the stronger
the adjustment intensity. The value 100
indicates that when the difference between the
PID feedback value and given value is 100%,
the range within which the PID regulator can
regulate the output frequency command is the
max. frequency (ignoring integral function and
differential function).
Setting range: 0.00–100.00
-182-
Function parameter list
Default Modify
○
0
○
1.80
