Goodrive350 IP55 High-ingress Protection Series VFD
Setting
EC PT100 detected OH
48
EC PT1000 detected OH
49
50 AIAO detected OH pre-alarm
Stopped or running in zero
51
52 Tension control disconnection
53 Specified roll diameter reached
54 Max. roll diameter reached
55 Min. roll diameter reached
56 Fire mode enabled
57–63
Related parameter list:
Function
code
P06.00 HDO output type
P06.01
P06.02
P06.03
P06.04
Function
pre-alarm
pre-alarm
speed
Reserved
Name
Y1 output
HDO output
RO1 output
RO2 output
Pre-alarm of overheating (OH) detected by the
expansion card (EC) with PT100.
Pre-alarm of overheating (OH) detected by the
expansion card (EC) with PT1000.
Overheating detected by the temperature detection AI
or AO terminal.
The VFD is stopped or running at zero speed.
Disconnection is detected when the tension-specific
function disconnection detection is enabled.
The specified roll diameter is reached when the
tension-specific function is enabled.
The max. roll diameter is reached when the
tension-specific function is enabled.
The min. roll diameter is reached when the
tension-specific function is enabled.
The fire mode is enabled.
/
Description
0: Open collector high-speed pulse output
1: Open collector output
0: Disable
1: Running
2: Running forward
3: Running reversely
4: Jogging
5: VFD in fault
6: Frequency level detection FDT1
7: Frequency level detection FDT2
8: Frequency reached
9: Running at zero speed
10: Frequency upper limit reached
11: Frequency lower limit reached
12: Ready for running
13: Pre-exciting
-94-
Basic operation guidelines
Description
Default
0
0
0
1
5
