P12.16 Rated frequency of SM 2 0.01Hz–P00.03 (Max. output frequency)
Number of pole pairs of
P12.17
P12.18 Rated voltage of SM 2
P12.19 Rated current of SM 2
P12.20 Stator resistance of SM 2 0.001–65.535Ω
Direct-axis inductance of
P12.21
Quadrature-axis
P12.22
inductance of SM 2
Counter-emf constant of
P12.23
5.5.7 Start/stop control
The start/stop control of the VFD involves three states: start after a running command is given
at power-on; start after power-off restart is effective; start after automatic fault reset. The three
start/stop control states are described in the following.
There are three start modes for the VFD, which are start at starting frequency, start after DC
braking, and start after speed tracking. You can select the proper start mode based on actual
conditions.
For large-inertia load, especially in cases where reversal may occur, you can choose to start
after DC braking or start after speed tracking.
Note: It is recommended to drive SMs in direct start mode.
