Goodrive350 IP55 High-ingress Protection Series VFD
Function
code
P00.11 ACC time 1
P00.12 DEC time 1
P05.01– Digital input function
P05.06 selection
Amplitude of wobbling
P08.15
frequency
Amplitude of sudden
P08.16
jump frequency
Rise time of wobbling
P08.17
frequency
Fall time of wobbling
P08.18
frequency
5.5.17 Local encoder input
The VFD supports pulse count function by inputting the count pulse from HDI high-speed pulse
port. When the actual count value is no less than the set value, digital output terminal will
output count-value-reached pulse signal, and the corresponding count value will be zeroed
out.
Function
code
P05.00
Name
7: PID control
8: Modbus/Modbus TCP communication
9: PROFIBUS/CANopen/DeviceNet communication
10: Ethernet communication
11: High-speed pulse HDIB
12: AB pulse train
13: EtherCAT/PROFINET/ EtherNet IP
communication
14: Programmable card
0.0–3600.0s
0.0–3600.0s
26: Pause wobbling frequency (stopped at the
present frequency)
27: Reset wobbling frequency (returned to the
center frequency)
0.0–100.0% (of the set frequency)
0.0–50.0% (of the amplitude of wobbling frequency)
0.1–3600.0s
0.1–3600.0s
Name
HDI input type
Description
Description
0x00–0x11
Ones place: HDIA input type
-107-
Basic operation guidelines
Default
Model
depended
Model
depended
See
"Group
P05––
Input
terminal
functions"
0.0%
0.0%
5.0s
5.0s
Default
0x00
