INVT Goodrive350 Series Operation Manual page 62

Goodrive350 IP55 High-ingress Protection Series VFD
Function
Name
code
Number of pole
P02.17
pairs of SM 1
Rated voltage of
P02.18
SM 1
Rated current of
P02.19
SM 1
Function
selection of
P05.01– multifunction
P05.06 digital input
terminals (S1–
S4, HDIA, HDIB)
P07.01 Reserved
Function of
P07.02
QUICK/JOG
5.5.3 Vector control
AMs feature high order, nonlinearity, strong coupling and multi-variables, which increase
difficulty to control AMs during actual application. The vector control technology solves this
situation as follows: measures and controls the stator current vector of the AM, and then
decomposes the stator current vector into exciting current (current component that generates
internal magnet field) and torque current (current component that generates torque) based on
field orientation principle, and therefore controls the amplitude values and phase positions of
the two components (namely, controls the stator current vector of the AM) to realize decoupled
control on exciting current and torque current, thus achieving high-performance speed
regulation of the AM.
The VFD uses the sensor-less vector control algorithm, which can be used to drive AMs and
permanent-magnet SMs simultaneously. As the core algorithm of vector control is based on
1–50
0–1200V
0.8–6000.0A
36: Switch the running command channel to keypad
37: Switch the running command channel to terminal
38: Switch the
communication
/
Range: 0x00–0x27
Ones place: Function of QUICK/JOG
0: No function
1: Jog
2: Reserved
3: Switch between forward and reverse rotating
4: Clear the UP/DOWN setting
5: Coast to stop
6: Switch command channels in sequence
7: Reserved
Tens place: Reserved
-44-
Description
running command
Basic operation guidelines
Default
2
Model
depended
Model
depended
See
"Group
P05––
channel to Input
terminal
functions"
/
0x01
