Goodrive350 IP55 High-ingress Protection Series VFD
Function
Name
code
AO1 output lower
P06.17
limit
AO1 output
P06.18 corresponding to
lower limit
AO1 output upper
P06.19
limit
Description
17: Value 2 set through
PROFIBUS/CANopen/DeviceNet
communication (0–1000)
18: Value 1 set through Ethernet
communication (0–1000)
19: Value 2 set through Ethernet
communication (0–1000)
20: HDIB input (0.00–50.00kHz)
21: Value 1 set through
EtherCAT/PROFINET/EtherNet IP
communication (0–1000)
22: Torque current (bipolar, 0–Triple the motor
rated current)
23: Exciting current (bipolar, 0–Triple the motor
rated current)
24: Set frequency (bipolar, 0–Max. output
frequency)
25: Ramp reference frequency (bipolar, 0–Max.
output frequency)
26: Rotational speed (bipolar, 0–Speed
corresponding to max. output frequency)
27: Value set through
EtherCAT/PROFINET/EtherNet IP (0–1000)
28: AO1 from the programmable card (0–1000)
29: AO2 from the programmable card (0–1000)
30: Rotational speed (0–Twice the motor rated
synchronous speed)
31: Output torque (Actual value, 0–Twice the
motor rated torque)
32: AIAO detected temperature output
33–63: Reserved
The function codes define the relationship
between the output value and analog output.
When the output value exceeds the allowed
range, the output uses the lower limit or upper
limit.
When the analog output is current output, 1mA
equals 0.5V.
-164-
Function parameter list
Default Modify
○
0.0%
○
0.00V
○
100.0%
