● SSSW-SW04
Functional Construction
Bit
0 LC monitoring
1 Check the CI signal frequency
2 Final flag sequences of the procedure signal
3 Reception mode after sending CFR signal
4 Time to ignore low-speed signals after sending CFR signal
5 Check the CS signal frequency (when PBX is set)
6 CNG signal at the time of manual sending
7 CED signal at the time of manual reception
Detailed Discussions of Bit 1
Select whether to check the CI signal frequency.
Detailed Discussions of Bit 2
Select the number of the final flag sequences with the procedure signal (300 bps transmission speed).
Select "2" when the other party's machine does not properly receive the procedure signal sent by this machine.
NOTE:
Error codes occurring at the time of sending fax
##100, ##280, ##281, ##750, ##753, ##754, ##755, ##758, ##759, ##760, ##763, ##764, ##765, ##768, ##769, ##770, ##773,
##775, ##778, ##780, ##783, ##785, ##788
Detailed Discussions of Bit 3
Select a reception mode after sending CFR signal.
Select "High speed" in the case of frequent errors caused by line condition at the time of reception. Simultaneously, turn
"OFF" the "ECM reception" of the user data.
NOTE:
Error codes caused by line condition at the time of reception
##107, ##114, ##201
Be sure to change bit 4 before changing this bit; if errors still occur, change this bit.
When 'high speed' is selected, only high-speed signals (images) will be received after sending the CFR signal.
Detailed Discussions of Bit 4
Select the time length during which low-speed signals are ignored after sending the CFR signal.
Select "1500 msec" when reception of image signal is difficult because the line condition is not good.
Detailed Discussions of Bit 5
Select whether to check the CI signal frequency when PBX is set.
Detailed Discussions of Bit 6
Select whether to send CNG signal at the time of manual sending.
If error occurs frequently at manual sending when the destination device that has FAX/TEL switch mode does not change
to the fax mode, select "Send".
Detailed Discussions of Bit 7
Select whether to send CED signal at the time of manual reception.
Select "Send" when the other party's machine does not start sending although manual reception is executed.
● SSSW-SW05
Functional Construction
Bit
0 Not used
1 To execute mm/inch conversion (text mode).
2 Not used
Function
Function
