COPIER (Service mode for printer) > OPTION (Specification setting mode) > NETWORK
SIPREGPR
Detail
Use Case
Adj/Set/Operate Method
Display/Adj/Set Range
Default Value
Additional Functions
Mode
VLAN-SW
Detail
Use Case
Adj/Set/Operate Method
Display/Adj/Set Range
Default Value
Supplement/Memo
FTPMODE
Detail
Use Case
Adj/Set/Operate Method
Display/Adj/Set Range
Default Value
SSLMODE
Detail
Use Case
Adj/Set/Operate Method
Display/Adj/Set Range
Default Value
Additional Functions
Mode
2
Setting of registrar server use protocol
To set the protocol used for communication with registrar server.
Although the protocol that is the same as the one for proxy server is usually used, another protocol
can be used in accordance with user and environment.
Upon user's request (to use a protocol different from the one for proxy server)
Enter the setting value, and then press OK key.
0 to 3
0: Protocol set in Settings/Registration menu, 1: UDP, 2: TCP, 3: SSL
0
Preferences> Network> TCP/IP Settings> SIP Settings> Intranet Settings
2
ON/OFF VLAN participation packets send
To set whether to send packets for participating in dynamic VLAN at link-up.
When participating in dynamic VLAN
Enter the setting value, and then press OK key.
0 to 1
0: OFF, 1: ON
0
- VLAN (Virtual LAN): A method for realizing grouping of terminals depending on the hub, switch
connection port, MAC address, protocol, etc.
- At link-up: At startup, when LAN cable is connected, when recovering from deep sleep, when
pressing the button to reflect the setting (dynamic update)
- If IP address of the machine has not been set, an IP address is assigned after participating in
VLAN.
1
Set of FTP print default operation mode
To set the default operation mode of FTP print.
Switch the default operation mode between ASCII mode and BIN mode in accordance with user's
environment.
At installation
1) Enter the setting value, and then press OK key.
2) Turn OFF/ON the main power switch.
0 to 1
0: ASCII mode, 1: BIN mode
0
2
Setting of HTTP/HTTPS port open/close
*Operation on this item is restricted by the setting of [Restrict Service Representation Access].
To set whether to open or close HTTP/HTTPS port.
When 1 is set while [Use HTTP] is ON and [Use TLS] is OFF in Settings/Registration menu, HTTP
port is opened whereas HTTPS port is closed.
When 2 is set while both [Use HTTP] and [Use TLS] are ON in Settings/Registration menu, HTTP
port is closed whereas HTTPS port is opened.
When limiting the port to open because of security concern
1) Enter the setting value, and then press OK key.
2) Turn OFF/ON the main power switch.
0 to 2
0: Normal, 1: Open HTTP port (80/8000) only, 2: Open HTTPS port (443/8443) only
0
Preferences> Network> TCP/IP Settings> Use HTTP
Management Settings> License/Other> MEAP Settings> Use TLS
475
8. Service Mode
