Canon imageRUNNER ADVANCE 715 series Service Manual page 455

COPIER (Service mode for printer) > FUNCTION (Operation / inspection mode) > SYSTEM
FIXIP
Detail
Use Case
Adj/Set/Operate Method
Caution
■ DBG-LOG
COPIER (Service mode for printer) > FUNCTION (Operation / inspection mode) > DBG-LOG
LOG2USB
Detail
Use Case
Adj/Set/Operate Method
Caution
Display/Adj/Set Range
Related Service Mode
LOG2SRVR
LOG-TRIG
Detail
Use Case
Adj/Set/Operate Method
Display/Adj/Set Range
Related Service Mode
HIT-STS
Detail
Use Case
Adj/Set/Operate Method
Display/Adj/Set Range
Related Service Mode
SYSLOG
1 Start of fixed IP mode
IP address is set to "172.16.1.100".
In an environment where wired LAN (main) and wireless LAN (sub) are used, the IP address of
wired LAN becomes the fixed IP.
During the fixed IP mode, "FIXIP" is displayed on the upper left of the screen.
When preferring to use the network settings with the fixed IP address "172.16.1.100"
Select the item, and then press OK key.
- It is necessary to turn OFF/ON the power to recover from the fixed IP mode.
- Whether to use RUI or not when the fixed IP mode is enabled follows the setting of "Management
Settings> License/Other> Remote UI.
2 Storage of debug log to USB memory
To store a set of debug logs to the USB flash drive at the error occurrence.
A type of log to be collected is set in LOG-TRIG.
If there is a debug log which has been automatically saved, it is archived at this time.
Required time differs according to the device conditions and volume of log data.
When analyzing the cause of a problem
1) Install the USB flash drive.
2) Select the item, and then press OK key.
- Wait until the machine recognizes the USB memory (approx. 10 sec.).
- During the data transfer ("ACTIVE" display), do not turn OFF the power/remove the USB memory/
use the screen for operations.
During operation: ACTIVE, At normal termination: OK, At abnormal termination: NG
COPIER> FUNCTION> DBG-LOG> LOG-TRIG
2 For R&D
2 Set of debug log storage condition
To set the conditions (timing, types, etc.) to automatically store the debug logs (stored as an archive
file).
By reading the operation setting file of the setting value from the Main Controller, the conditions
written in the file are set.
When setting a new condition is necessary, read the operation setting file provided by R&D from
the USB memory.
- When changing the conditions of debug log to automatically store
- When setting a new condition
Enter the setting value, and then press OK key.
0 to 99999
COPIER> FUNCTION> DBG-LOG> LOG2USB, LOG2SRVR
2 Display of debug log state
To display whether archive file of the debug log which is matched with the conditions set in LOG-
TRIG exists or not.
When checking the debug log automatically saved
N/A (Display only)
0 to 1
0: No log is available, 1: Log is available
COPIER> FUNCTION> DBG-LOG> LOG-TRIG
2 For R&D
445
8. Service Mode
