Canon imageRUNNER ADVANCE 715 series Service Manual page 172

3. Remove the Rear Upper Cover [1].
• 2 Screws [2]
• 2 Bosses [3]
4. Remove the Flat Cable [2] from the Main Controller PCB [1].
• 1 Flat Cable [2]
• 1 Harness Guide [3]
5. Remove the Cable [1] from the Harness Guide [2].
• 1 Harness Guide [2]
• 5 Conners [3]
2x
[3]
[2]
1x
1x
[1]
5x
2x
[1]
[3]
[1]
[3] [2]
[1]
[2]
[3]
[3]
162
4. Parts Replacement and Cleaning
[3]
[2]
