363-206-285
Issue 2, February 2000
Letter "d" or "P." in FE ID Display
!
19.
CAUTION:
If PC hard drive is being used, ensure you are in the correct directory. If
floppies are being used, ensure the first (number 1) diskette is installed in
floppy drive. Ensure PC is connected to the front CIT (CIT-1) connector.
Enter term or term COMn command, where n = 1 or 2. If term is entered
without the COMn option, then COM1 will be selected by default. Disregard
message Can't find script <init> if you see it after starting the
terminal emulator.
Response:
20. Unplug and reseat the SYSCTL and immediately push and hold the FE SEL
and UPD/INIT buttons at the same time until a P appears in the FE ID display
(takes approximately 15 seconds). The software download automatically
begins and may take 20 to 45 minutes.
Response:
21. Was response correct?
If YES, then continue with Step 22.
If NO, then proceed to Step 27.
Two brief messages are printed and you are instructed to
Press any key to continue . . . after the
second message. After you press any key, the terminal
emulator is loaded and the terminal responds as follows:
CTRM ready. (Type Alt-h for help.)
Communications established.
PC starts download and prints the following message:
Searching for optimal transfer rate.
Handshake established at <baudrate> baud.
In progress . . . .
The dots continue to print until program installation is
complete. If using the floppy disks, insert each diskette
when prompted. After installation is completed, the PC
prints the following completion message:
ins-prog:TID COMPLD
/* Generic a.b.c is installed */
The SYSCTL resets and the terminal is logged off the
system.
DDM-2000 OC-3 M
Detailed Level Procedure:
ULTIPLEXER
DLP-532
Page 10 of 14
