You can adjust the length of the gap or center segment in an individual grid line. For example, you may
want to adjust the gap so the grid line does not display through the middle of a model element. See
Adjusting the Center Segment of a Grid Line
Tag Label Enhancements
A new Edit Label dialog replaces the Select Parameter dialog in the Annotation Family Editor. You use this
new dialog to create multi-parameter concatenated labels.
See Tagging with Shared Parameters
Beam Tags and Spot Elevations
You can place structural framing tags and spot elevations anywhere above or below a beam using new tools
that specify the location and offsets of the label. You can place tags individually or on all beams currently
in view. See
You can set tags and spot elevations to rotate in reference to a beam's location and rotation. This allows the
placement of a tag that moves and repositions with the beam. See
853.

Text Note Styles

You can now create or modify text note styles using Settings
Note Styles

Editing Elements

This topic describes the new and enhanced features for editing elements in Revit Architecture 2009.
Linework Enhancements
You can use the Linework tool to change the line style for selected edges of model elements in a view,
including the following:
Projection edges of model elements
Cut edges of model elements
Edges in imported CAD files
Edges in linked Revit models
See Changing the Line Style of Elements

Revisions and Sheets

This topic describes the new and enhanced features for revisions in Revit Architecture 2009.
Beam Annotations Tool
on page 500.
on page 1096.
on page 455.
on page 853.
on page 398.
Structural Framing Tag Families
Annotations Text. See
Editing Elements | 77
on page
Specifying Text
