Project Browser

The Project Browser shows a logical hierarchy for all views, schedules, sheets, families, groups, linked Revit
models, and other parts of the current project. As you expand and collapse each branch, lower-level items
display.
To change the size and location of the Project Browser
To show the Project Browser, click View tab
box.
To hide the Project Browser, click View tab
the Close button (the red X) at the top of the browser.
To resize the Project Browser, drag one of its borders.
To move the Project Browser, drag the browser s title bar within the Revit window. As you move the
cursor, an outline indicates where the browser will move to, and what its shape will be. Release the mouse
button to place the browser in the desired location. You can also drag the Project Browser outside the
Revit window to the desktop.
To float the Project Browser in the drawing area, double-click its title bar. You can then move the browser
to the desired location, and drag its borders to resize it.
You can customize the organization of project views in the Project Browser. See
Organization in the Project Browser
Changes to the size and location of the Project Browser are saved and restored when the application is
restarted.
Using the Project Browser
The Project Browser is a powerful way to navigate and manage complex projects.
Views, Schedules, Sheets
If you want to...
open a view
User Interface panel, and select the Project Browser check
User Interface panel, and clear Project Browser, or click
on page 255.
then...
double-click the name of the view, or right-click the name and click Open from
the shortcut menu. The active view name displays in bold.
Customizing Project View
Parts of the Revit Interface | 93
