Planmeca ProMax 3D Max with ProTouch Technical Manual page 87

Error Explanation
code
E267 Patient support error
E270 Timeout
E273
E274
E275
E277
E278
E279
E280
E281
E282 Timeout
E283
E284
Technical manual
Patient support moved during the
patient support locking mechanism.
Timeout in lift motor which is connected
to PSU PCB J10.
Timeout in temple rest motor which is
connected to PPC PCB J5 and
controlled by MCM module 3.
Timeout in scanning cephalostat motor
which is connected to CEPH PCB J2
and controlled by MCM module 3.
Timeout in patient support motor which
is connected to CPU PCB J20 and
controlled by MCM module 3.
Timeout in collimator Y1 upper motor
which is connected to CAM PCB J23
and controlled by MCM module 5.
Timeout in collimator X motor which is
connected to CAM PCB J24 and
controlled by MCM module 5.
Timeout in collimator X1 right motor
which is connected to CAM PCB J24
and controlled by MCM module 5.
Timeout in collimator Y motor which is
connected to CAM PCB J25 and
controlled by MCM module 5.
Timeout in tube head rotation motor
which is connected to CAM PCB J22
and controlled by MCM module 6.
Timeout in collimator filter revolver
motor which is connected to CAM PCB
J22 and controlled by MCM module 6.
Timeout in collimator filter motor which
is connected to CAM PCB J20 and
controlled by MCM module 7.
Timeout in collimator X2 left motor
which is connected to CAM PCB J20
and controlled by MCM module 7.
3 Help and error messages
Comments
Check the patient
support optical sensor
position.
If necessary, install
patient support friction
pad. For more
information, see the
retrofit installation
instructions
(publication number
30006217).
Check the sensor,
cable, motor and the
PSU PCB.
Check the sensors,
cables and the motor.
Check the sensors,
cables and the motor.
Check the sensors,
cables and the motor.
Check the sensors,
cables and the motor.
Check the sensors,
cables and the motor.
Check the sensors,
cables and the motor.
Check the sensors,
cables and the motor.
Check the sensors,
cables and the motor.
Check the sensors,
cables and the motor.
Check the sensors,
cables and the motor.
Check the sensors,
cables and the motor.
Planmeca ProMax 3D Max 81
