8.1.4.1 Removing tube head front cover
Technical manual
The tube head front cover is secured with four screws (two at the top and
two at the bottom).
1. Unscrew the two top screws (1) and the two bottom screws (2), see the
figure below.
2. Remove the cover.
8 Parts replacement and repair
Planmeca ProMax 3D Max
195
