Feedback Errors (E4Xx) - Planmeca ProMax 3D Max with ProTouch Technical Manual

Error Explanation
code
E313
E317
E321 Tube current
E322
E323
E332 Arcing
E334
E336
E342 Monitoring errors
E343

3.2.3 Feedback errors (E4xx)

Technical manual
Tube voltage too high.
Tube voltage overshot suddenly without
arching.
Tube current missing completely.
Tube current too low.
Tube current too high.
Severe arcing across the X-ray tube.
Severe arcing at tube head anode end.
Severe arcing at tube head cathode
end.
Exposure pulsing fault.
Conflict between assembled and
configured X-ray tube type.
The following table lists the feedback errors.
3 Help and error messages
Comments
Exposure not
possible. Check the
prefilament values are
correct or perform the
prefilament calibration
again.
Exposure interrupted.
Check the interface,
cabling and the PSU
PCB.
Exposure interrupted.
Check the interface,
cabling and the PSU
PCB.
Exposure interrupted.
Check the interface,
cabling and the PSU
PCB.
Exposure interrupted.
Perform the preheat
calibration again.
Check the interface,
cabling and the PSU
PCB.
Exposure interrupted.
Check the tube head
functionality. If the X-
ray unit has not been
used for a week or
more, carry out the
tube head seasoning
process (1520 Tube
Head Seasoning).
Exposure interrupted.
Exposure interrupted.
Exposure not
possible.
Check that correct
type of tube head is
selected in the 3100
Unit Configuration
menu, in Tube Type
setting.
Planmeca ProMax 3D Max 83
