Infrastructure Errors (E9Xx) - Planmeca ProMax 3D Max with ProTouch Technical Manual

Error Explanation
code
E819
E821 Software compatibility CPU FPGA version not compatible with
E822
E834
E835
E836
E841 Missing MCM
E842
E843
E844
E845
E846
E847
E848

3.2.7 Infrastructure errors (E9xx)

Error Explanation
code
E904 Checksum error in
E905
E915
E926
E927
Technical manual
Ceph CA not found.
the main software.
CAM FPGA version not compatible with
main software.
Dimax sensor type too old.
Movement prevented due to missing
jumper J8 on patient position control
PCB or broken patient positioning
cable.
Wrong C-arm PCB version for 120kV
device.
Missing MCM module 1.
Missing MCM module 2.
Missing MCM module 3.
Missing MCM module 4.
Missing MCM module 5.
Missing MCM module 6.
Missing MCM module 7.
Missing MCM module 8.
The following table lists the infrastructure errors.
Checksum error in RTC- EEPROM.
Checksum error in tubehead EEPROM. Check the cabling
RTC RAM error.
General geometry calculation error.
PathFinder out of memory
3 Help and error messages
Comments
Check the cabling
between the CEPH
PCB and CPU PCB.
Check the
functionality of the
CPU PCB.
Check the software
version of the ProMax
X-ray unit.
The Dimax sensor
version is too old or
not compatible with
the ProMax X-ray unit
software version.
Comments
and the functionality
of the FBK PCB.
The latest settings are
not stored in memory.
Check the RTC PCB
and cabling.
Planmeca ProMax 3D Max 89
