2 User interface

2 User interface

2.1 Switches and buttons

2.1.1 On/off switch

2.1.2 Emergency button

34 Planmeca ProMax 3D Max
The On/Off switch is located on the underside of the stationary column top.
When you switch the X-ray unit on the main display will be shown on the
control panel and the X-ray unit will carry out a self-test which takes
approximately 75 seconds.
The X-ray unit is then ready for use.
NOTE
When restarting the X-ray unit, let the unit stay at least 10 seconds in Off-
state, to ensure that all X-ray unit internal processes are completely closed
thus enabling a clean restart.
NOTE
To prolong the lifetime of the Planmeca ProMax X-ray unit, always switch off
the X-ray unit when it is not in active use.
The emergency stop button is located on the top of the stationary column.
Press the emergency button to stop the X-ray unit operating in an
emergency. When the emergency stop button is pressed down, all
movements of the X-ray unit are blocked and the unit will not generate
radiation. The up / down movement will stop within a distance of 10 mm (0.4
in.).
A help message will appear on the touch screen. Guide the patient away
from the X-ray unit. Then release the emergency stop button. The X-ray unit
automatically restarts.
