8 Parts replacement and repair
Steps
1. Input mains line (L)
3. Ground
214 Planmeca ProMax 3D Max
1. Remove the column top cover. For more information, see the column
PCB replacement section in this chapter.
2. Remove the power cable parts from their connections.
The following cabling placements are important:
3. Remove the power cable (1) and remove the plastic housing (2).
2. Neutral (N)
4. Cable tie
