Planmeca ProMax 3D Max with ProTouch Technical Manual page 30

1 General and technical data
2
3
4
Item B
Deviation from the default CT scanner conditions of
operation
Tube voltage: 60 kV
Tube voltage: 90 kV
Tube current: 1 mA
Tube current: 6.3 mA
Tube Current: 11 mA
Exp. mode: Low dose
Exp. mode: High resolution
Exp. mode: HD
Exp. mode: Endo
Exp. mode: Low dose (offset scan)
Exp. mode: HD (offset scan)
Exp. mode: ULD Low dose
Exp. mode: ULD Normal
Exp. mode: ULD High resolution
Exp. mode: ULD HD
Exp. mode: ULD Endo
Exp. mode: ULD Low dose (offset scan)
Exp. mode: ULD Normal (offset scan)
Exp. mode: ULD HD (offset scan)
Exp. mode: Braces
Width: 50 mm
Width: 130 mm
24 Planmeca ProMax 3D Max
The location of the position where the CTDI
1 cm in from the surface of the phantom as specified for this measurement)
is on the mid sagittal line of the imaged volume, posterior to the axis of
rotation.
C-arm: CTDI
100 (peripheral, max)
CTDI
100 (peripheral, 90°)
CTDI
100 (peripheral, 180°)
CTDI
100 (peripheral, 270°)
The average peripheral CTDI
NOTE
Values in this item are normalised to the CTDI
100
= 20.04 mG
= 14.08 mGy
= 3.60 mGy
= 15.17 mGy
value, CTDI
100 100 (peripheral)
100 (centre)
Relative CTDI
0.05
0.36
0.12
0.78
1.34
0.50
1.00
1.22
1.22
0.65
1.31
0.24
0.32
0.32
0.40
0.40
0.32
0.32
0.43
0.40
0.75
0.65
has the maximum value (i.e.
= 13.32 mGy
in Item A 1.
100 (centre)
