Planmeca ProMax 3D Max with ProTouch Technical Manual page 82

3 Help and error messages
Code
H130 Patient safety area
H142 Height movement
H144
H148
H149
H150
H151 Line voltage
H152
H161 Temperature
H162
H163
H165
H166
H170 User related
messages
H171
H172
H175
H180
H181
76 Planmeca ProMax 3D Max
Explanation
Patient safety area violation
detected.
Height movement is not possible
because one (or more) of the
positioning control buttons or the
positioning joystick is stuck.
Height movement is not possible
because one (or more) of the
positioning control buttons is stuck.
Height movement is not possible.
The position of the patient support
table is too high.
Height movement was stopped
because the C-arm cannot be
moved lower.
Height movement was stopped
because the patient support table
cannot be moved lower.
The line voltage was too low during
exposure.
The line voltage is too low.
The temperature of the tube head is
too high.
The temperature of the lift motor is
too high.
The temperature of the tube head is
too high. Please wait for tube head
to cool down for beam check.
The temperature of the tube head is
too high for the selected exposure
values.
The maximum tube head energy
level was exceeded.
Wrong licence code.
The sensor is not attached properly
to the C-arm.
The sensor is not attached properly
to the cephalostat.
PC program selection is in conflict
with the selected X-ray unit program.
DEC is not available.
The imaging process was cancelled
in Planmeca Romexis.
Comments
Check the scan and layer
settings.
Clear any obstruction before
moving the column again.
Release the button / joystick.
Press the X-ray unit down
button to move the patient
support table down.
Clear any obstruction before
continuing.
Clear any obstruction before
continuing.
Exposure was interrupted.
Contact your service
technician for help.
Exposure is not possible.
Contact your service
technician for help.
Wait for a few minutes for the
tube head to cool down.
Wait for a few minutes for the
lift motor to cool down.
Wait for tube head to cool
down for beam check.
Wait for a few minutes for the
tube head to cool down.
Wait for a few minutes for the
tube head to cool down or
use lower exposure values.
Check the licence code.
Attach and / or lock the
sensor in position.
Attach and / or lock the
sensor in position.
Select another exposure
mode in Planmeca Romexis.
