3 Help and error messages
Error Explanation
code
E451 Key stuck elsewhere

3.2.4 Communication errors (E6xx)

Error Explanation
code
E601 Internal (CAM)
E602
E603
E604
E605
E606
E607
E608
E611 Internal (other)
E612
86 Planmeca ProMax 3D Max
Error in cephalostat Up / Down switch
which is connected to CEPH PCB J3.
The following table lists the communication errors.
Total data communication failure
towards CAM.
Total data communication failure from
CAM.
Data errors towards CAM.
Data errors received from CAM.
No clock signal received at CAM.
Data line polarity is wrong at CAM.
No clock signal received from CAM.
Data line polarity is wrong from CAM.
Error in communication with RTC.
Error in communication with tube.
Comments
Check the button.
Comments
Exposure not
possible. Check the
cable of the CAM
PCB and that it is
installed correctly.
Exposure not
possible. Check the
cable of the CAM
PCB and that it is
installed correctly.
Check the cable of
the CAM PCB and
that it is installed
correctly. Check the
functionality of the
battery and that it is
installed correctly.
Check the cable of
the CAM PCB and
that it is installed
correctly.
Check the cable of
the CAM PCB and
that it is installed
correctly. Check the
functionality of the
battery and that it is
installed correctly.
Check the cable of
the CAM PCB and
that it is installed
correctly.
Check the RTC and
the CPU PCB and the
cabling.
Check the cabling
between the CAM
and FBK PCB. Check
the functionality of the
FBK PCB.
